8D Hermetic Series

8D Hermetic Series

  • Extreme low leak rate
  • High density
  • Quick and robust coupling system
  • Customizable to any need
  • Qualified according to Mil-C-38999 series III standard
  • Operating temperature: -65°C to 200°C
  • Hermeticity: 10-7 atm.cm3/s under helium

Key features and benefits

Description

The 8D hermetic series is a receptacle connector with thread coupling system according to MIl-DTL-38999 series III standard.

8D hermetic series have a receptacle connector with stainless steel housing and thread coupling interface which allow a quick and reliable mating.

A high density solution is available by using contacts size 22.

8D hermetic connectors are available in solder flange for compactness and perfect hermeticity, in square flange configuration for a very easy installation and in jam-nut for a simple replacement.

The connector is made of stainless housing to withstand harsh environment.

Examples of application field

8D hermetic connectors are suited to withstand harsh environments in aviation applications.
