- 3 coupling options
- Different materials: aluminum, stainless steel or composite material
- EMI/RFI protection
- Compatible with the main circular connector standards MIL-DTL-26482 backshell
Key features and benefits
AS85049 Backshell Description
The AS85049 backshell series regroups all our military standard QPL backshells. AS85049 backshells are designed to fit the main circular connectors used in our industry (MIL-DTL-26482 series II backshell, 83723 series 1 & 3, 38999 Series I, II, III & IV); they are qualified for aluminum, stainless steel or composite material (many plating proposed).
Two self-locking technologies were developed: a detented system and the SUNBANK Self-seating mechanism that exceeds the vibration requirements. A free rotatable coupling is also available.
Qualified for multiple EMI/RFI designs, SUNBANK AS85049 backshells are available in banding and crimping platforms for overall shielding, dual EMI ring for overall and individual shielding. The MIL-DTL-26482 backshell bodies are specifically designed to optimize weight and robustness. The Self-seating locking option offers lighter weight and lower profile backshell than a detented system.
SUNBANK offers AS85049/128 qualified bands as well as AS85049/93 shield support rings. Tools are also available to terminate your wiring assembly.
AS85049 backshells can be ordered with various interfaces depending on the connector used. Both American and European standards are covered, such as D38999, M26482, EN2997, EN3645, M5015, etc.
A wide range of SUNBANK backshells provide waterproofing and environmental sealing withstanding most severe shock, vibration, cable pullout and external bending moment.
Build a Backshell
Examples of application field
M85049 backshells are designed to fit the main circular connectors used in our industry.
